| Basic Parameters | Specification |
| Grid output Parameters(ac) | |
| Rated AC output power | 5000VA |
| Rated AC output current | 21.7A |
| THDI | <3% |
| Rated grid voltage/Grid voltage range | 230Vac/176-270Vac |
| Rated grid frequency/Grid frequency range | 50Hz(45-54Hz)/60Hz(55-65Hz) |
| Type of grid connection | AC Charging connector |
| Eps output | |
| EPS rated voltage | 220/230/240Vac |
| EPS rated frequency | 50/60Hz |
| Max. EPS power | 5000VA |
| EPS overload protection | 150%,30S |
| THDU | <2% |
| Type of output connection | Socket panel、AC Charging connector |
| Switch times | <20mS |
| Battey Parameter | |
| Battey type | LiFePO4 battery |
| Battey rated voltage | 51.2V |
| Capacity | 100AH |
| Battey voltage range | 42-58V |
| Max. charging current | 75A |
| Max. discharging current | 100A |
| Other System Parameter | |
| Max. efficiency | 95% |
| Cooling method | FAN |
| Storage/Operation relative hunidity | 10-90% |
| Operating temperrature range | -20°C~50°C |
| Max. charging current | 2000m |
| Dimension(W*D*H) | 700*424*482mm |
